Dream+ led panel 40W (595x595x11mm) 5,000K CRI>90 UGR<19 ex. driver
108,10
Description
The 5000K Dream LED panel delivers a very friendly light image, it is the ideal luminaire for warehouses, hospitals and workshops. The light image is determined by the applied prismatic coating, which ensures a glare factor lower than 19. In addition, the color rendering of the luminaire is very high (CRI > 90), colors are thus well and vividly displayed. The luminaires are constructed from high-quality components and equipped with high-quality LED chips, guaranteeing years of carefree lighting enjoyment. The Dream panel is available in various sizes and packaging forms.
The Dream+ panels are supplied without driver and can be combined with a suitable Interlight driver. Choose an on/off, 1-10 Volt, Dali or Thinq driver. Set the driver to a maximum of 1,050mA.
Specifications
| Brand | Interlight |
|---|---|
| Product type | Panel |
| Suitable for wall mounting | No |
| GTIN | 08719214379445 |
| Suitable for pendulum suspension | Yes |
| Suitable for ceiling mounting | Yes |
| Suitable for flush mounting | Yes |
| Suitable for surface mounting | Yes |
| Suitable for light line configuration | No |
| Suitable for monitor workplace according to EN 12464-1 | Yes |
| Lamp type | LED not interchangeable |
| With light source | Yes |
| Suitable for number of light sources | 1 |
| Lampholder | Other |
| Housing material | Aluminum |
| Surface protection housing | Lacquered |
| Housing color | White |
| Material cover | Plastic opal |
| Grid version | No |
| Voltage type | AC |
| Nom. voltage | 230 V |
| Nom. current | 0 – 1050 mA |
| Ballast | LED control current-controlled |
| Driver included | No |
| Interchangeable ballasts | Yes |
| Dimming dependent on driver | Yes |
| Light distributor | Diffuser lens/optics/panel |
| Light distribution | Symmetrical |
| Beam angle | >80° – Extremely wide beam |
| Light outlet | Direct |
| Energy efficiency class of the built-in lamp | A++, A+, A (LED) |
| Nom. life L90/B50 at 25 °C | 50000 h |
| Degree of protection (IP) | IP20 |
| Impact resistance | IK02 |
| Protection class according to IEC 61140 | II |
| Emergency power supply integrated | No |
| Nom. ambient temperature according to IEC62722-2-1 | -10 – 40 °C |
| With motion sensor | No |
| Specific luminous flux luminaire | 100 lm/W |
| Effective luminous flux according to IEC 62722-2-1 | 4000 lm |
| With light sensor | No |
| Cover fixture with thermal insulation material possible | No |
| With air slots | No |
| Glow wire test according to IEC 60695-2-11 | 650 °C – 30 s |
| Suitable for lamp power | 40 W |
| Max system power | 40 W |
| Light color | White |
| Color temperature | 5000 K |
| Color rendering index | 90-100 |
| Power factor | 0.9 |
| Width | 595 mm |
| Height/depth | 11 mm |
| Length | 595 mm |
| Type of wiring | End |
| Number of poles | 2 |
| Connection method | Plug clamp |
| UGR | 19 |
| Light color adjustable | No |
| Luminous flux adjustable | No |
| Beam angle adjustable | No |
