Sense led contour track spot 30W 24° 2,700-6,500K CRI95 black AI
557,20
Description
The Sense Trackspot is an advanced, smart spotlight that is fully digitally controlled. Unlike the Sense Trackspot, the Contour Trackspot does not have its own sensor. However, it can be paired with a Sense Trackspot in a group or set up manually using a specially developed app. In this app, it is possible to place multiple trackspots in a group, allowing them to be controlled together.
The Sense Contour Track Spot has an adjustable range from 2,700K to 6,500K and offers a full spectrum of light colors. With an impressive CRI value of 95 with color enhancement, this spotlight offers perfect light color.
The beam of the Contour Track Spot can be adjusted as desired. For example, the degree beam can be adjusted between 24 and 31 degrees, and the sharpness of the beam can also be adjusted. The presence of iron blades allows the beam to be adjusted to any desired shape, allowing variation when illuminating round, square and rectangular objects.
The Sense Trackspot can be used in Staff, Global and Nordic rail, among others. The track spot does not fit in an Erco and Eutrac rail.
RAL color: 7021
Specifications
| Brand | Interlight |
|---|---|
| Product type | Contour track spot |
| Suitable for surface mounting | No |
| GTIN | 08720195277989 |
| Suitable for flush mounting | No |
| Suitable for wall mounting | No |
| Suitable for pendulum suspension | No |
| Suitable for ceiling mounting | No |
| Suitable for truss mounting | No |
| Suitable for pedestal/floor mounting | No |
| Suitable for power rail mounting | Yes |
| Suitable for clamp mounting | No |
| Suitable for low voltage cable system | No |
| Adjustability | Rotatable and pivotable |
| With motion sensor | Yes |
| With light sensor | Yes |
| Lamp type | LED not interchangeable |
| With light source | Yes |
| Suitable for number of light sources | 1 |
| Housing material | Aluminum |
| Surface protection | Lacquered |
| Housing color | Black |
| Voltage type | AC |
| Nom. voltage | 220 – 240 V |
| Ballast | LED control current-controlled |
| Driver included | Yes |
| Dimmable | Yes |
| Interchangeable ballasts | No |
| Dimmable 0-10 V | No |
| Dimmable 1-10 V | No |
| Dimmable Dali-2 | No |
| Dimmable DALI | No |
| Dimmable DMX | No |
| Dimmable DSI | No |
| Dimmable with potentiometer (integrated) | No |
| Dimmable LineSwitch | No |
| Dimming manufacturer-specific | No |
| Dimmable mains voltage modulation | No |
| Dimmable phase cut | No |
| Dimmable phase cut | No |
| Dimming programmable | Yes |
| Dimmable RF | No |
| Dimmable Sine Wave Reduction | No |
| Dimmable Touch and Dim | No |
| Dimmable Zigbee | No |
| Not dimmable | No |
| Dimmable with push-button | No |
| Reflector | Mat |
| Light distributor | Reflector |
| Light distribution | Symmetrical/asymmetrical |
| Reflector color | Silver |
| Beam angle | 21-40° – Medium radiant |
| Light outlet | Direct/indirect |
| Constant luminous flux control | No |
| Degree of protection (IP) | IP20 |
| Protection class according to IEC 61140 | I |
| Nom. ambient temperature according to IEC62722-2-1 | -20 – 40 °C |
| Suitable for lamp power | 30 W |
| Max system power | 30 W |
| Luminous flux | 0 – 750 lm |
| Effective luminous flux according to IEC 62722-2-1 | 750 lm |
| Light color | White |
| Color temperature | 2700 – 6500 K |
| Light color adjustable | Stepless |
| Color rendering index | 90-100 |
| Effective luminous flux according to IEC 62722-2-1 | 0 – 750 lm |
| Luminous flux adjustable | Stepless |
| Beam angle adjustable | Stands |
| Length | 169 mm |
| Width | 209 mm |
| Height/depth | 160 mm |
| Outer diameter | 80 mm |
| Emergency power supply integrated | No |
| Max. number of fixtures per line protection switch B16 | 58 |
| Max. number of fixtures per line protection switch C16 | 58 |
| Suitable for monitor workplace according to EN 12464-1 | No |
| Cover fixture with thermal insulation material possible | No |
| Operation via App | Yes |
