SLK 3/5 connector 0.5-2.5mm2 5p+E piec PC opd. L1-N-E-D1-D2
873,10
Out of stock (back order possible)
Log in to see exact stock
Description
Price and purchase per 500 pieces.
Specifications
| Brand | Electro Terminal |
|---|---|
| Product type | Connector |
| Contact insert without contacts | No |
| GTIN | 09006604158360 |
| Contact version | Counter plug (female) |
| Number of poles | 5 |
| Diameter of plug-in contact | 2.5 mm |
| Connector insert material | Other |
| Nom. (measuring) current In | 24 A |
| Ambient temperature | 110 – 850 °C |
| Nom. (measuring) voltage | 450 V |
| Assigned impact stress | 175 kV |
| Electrical connection design | Plug valve connection |
| With wire protection | No |
| Connectable conductor cross-section fine wire without conductor end sleeve | 1.5 – 2.5 mm² |
| Connectable conductor cross-section fine wire with wire end sleeve | 0.5 – 2.5 mm² |
| Connectable conductor cross-section single wire | 0.5 – 2.5 mm² |
| Connectable conductor cross-section multi-wire | 0.75 – 2.5 mm² |
| Material contact coating | Zinc |
| Material contact | Bronze |
| Flammability class of insulation material in accordance with UL 94 | Other |
| With grounding conductor | No |
